Merak GPI Series_TCSN Power Technology (Shenzhen) Co.,Ltd

Model	TCGPI-P1M6K-EU	TCGPI-P1M8K-EU	TCGPI-P1M10K-EU	TCGPI-P1M12K-EU
Battery Input
Battery Type	Lead-acid or Li-ion
Battery Voltage Range (V)	40-60
Max Charge Current (A)	135	190	220	250
Max Discharge Current (A)	135	190	220	250
External Temperature Sensor	Yes
PV Input
Max DC Input Power (W)	9000	12000	13000	15600
Input Voltage (V)	370V(125V-500V)
MPPT Voltage Range (V)	150-425V
Full Load DC Voltage Range (V)	300-425V
Startup Voltage (V)	125V
PV Rated Input Current (A)	18+18	26+26	26+26+26	26+26+26
PV Max Input Current (A)	27+27	34+34	34+34+34	34+34+34
Number of MPPTs	2	2	3	3
Number of MPPT Trackers	1+1	1+1	1+1+1	1+1+1
AC Input/Output
Rated Output Power (W)	6000	8000	10000	12000
Max Output Power (VA)	6600	8800	11000	13200
Peak Power (Off-grid)	Twice the rated power for 10 seconds
Rated Input/Output Current (A)	27.3/26.1	36.4/34.8	45.5/43.5	54.6/52.2
Max Input/Output Current (A)	30/28.7	40/38.3	50/47.9	60/57.4
Max Continuous PT Current (A)	40	50	60	70
Power Factor	0.8 leading to 0.8 lagging
Output Voltage & Frequency	50/60Hz; 220/230Vac
Grid Type	Single-phase
Total Harmonic Distortion	<3% (of nominal power)
DC Component	<0.5% In
Efficiency
Max Efficiency	97.60%
European Efficiency	96.50%
MPPT Efficiency	>99%
Certifications & Standards
Grid Code	EMC/SAFETY REGULATION
EMC/Safety Standards	EN61000-6-2/-4;EN62109-1;EN62109-2
General Data
Operating temperature Range	-40 to 60?? derating above 55??/td>
Cooling Method	Smart cooling
Noise (dB)	<50 dB
Communication with BMS	RS485, CAN
Monitoring Method	WiFi+APP
Protection Rating	IP65
Installation Method	Wall-mounted
Weight (kg)	22	25.5	-	36
Dimensions (WHD)	340?490?256.22mm	340?560?257mm		430?629.9?256mm
